9662 Refrigeration Motor 1/20HP 115V 1550 RPM CW OAO BOHN
Refrigeration Motor
Cross Reference/Fit Models: Bohn, 5034L, 5034LS, 5008S, 5008SS Heatcraft, 2530001 Kramer/Trenton, 5KSM59ES2001, E206444 Larkin, 253-1194, 7163-2113, 7163-3371, JA2N016N, 7163-2135
Technical Specifications
| Application | Refrigeration Evaporator fan |
| Bearing Type | Ball |
| FLA at 115V (A) | 0.85 |
| High Speed (RPM) | 1550 |
| HP | 1/20 |
| Input Voltage (V) | 115 |
| Motor Type | RESCUE High Efficiency PSC |
| Mounting | 4 studs on each end |
| Overall Shaft Length (in.) | 3 |
| Rotation Direction (OSE) | Reversible |
| Shaft Diameter (in.) | 5/16 |
Free Shipping
| Shipping Weight Actual (lbs.): | 3.37 |
| Shipping Weight Dimensional (lbs.): | 6.03 |
| Shipping Height (in.): | 10.13 |
| Shipping Length (in.): | 14 |
| Shipping Width (in.): | 10.63 |
| UPC Number: | 662766652468 |
Notice: Heating, ventilation, air conditioning or refrigeration parts and accessories should only be installed by qualified technicians. Failure to understand and follow the manufacturer’s installation and use instructions may result in fire or explosion, electric shock, property damage, injury or loss of life.
It is your responsibility to seek professional advice when installing and using these parts and accessories. If installed improperly warranty will be voided.
Before ordering please verify this is the correct part for the unit it is being installed in. If installed improperly the warranty will be voided.
